Thermal Instrument Company - Engineering Questionnaire Form

Customer Contact Information

Customer Detail Notes

Please fill in as many details about your flow application as known. Please return this form to your local sales representative or email or fax to Thermal Instrument Company.

Flow Inquiry

Preferred Flow Sensor Style (Visit our website for more detail)

Model # 62-9 Insertion Probe Model # 600-9 In-line

Flow Application Details

Flow Range

Pressure Range

Temperature Range

Line Type Information

Duct : (If Rectangular, please provide dimensions)

Any Special Finish Required?

Flow Wetted Material Requirements (Standard 316SS)

Preferred Process Connections

Is the line full of fluid or partially full?

Any other comments or notes about your flow application?

Is the flow vertical, if so what direction is the flow traveling?

Do you have 10 pipe diameters of straight run on inlet and 5 pipe diameters of straight run on outlet side of instrument?

Flow Switch Details

Model # FS (Available as Integral or Remote Mount Only)

Field Adjustable 5 Amp SPDT Relay Alarm (1 Each)

Or

Model # FS16 (Integral Mount Only)

(2) Field Adjustable 10 Amp SPDT Relay Alarms or (1) Field Adjustable DPDT 10 Amp Relay Optional Temperature 4-20mA Output Optional Temperature Alarm

Power Requirements

Flow Switch Details

Model FS

Model FS16

Optional Temperature 4-20mA Output Optional Temperature Alarm
